Processor TypeIntel® Xeon® Scalable processors, 1st and 2nd generations
Processor family1st generation: Intel® Xeon® Scalable 8100 series, Intel® Xeon® Scalable 6100 series, Intel® Xeon® Scalable 5100 series, Intel® Xeon® Scalable 4100 series, Intel® Xeon® Scalable 3100 series; 2nd generation: Intel® Xeon® Scalable 8200 series, Intel® Xeon® Scalable 6200 series, Intel® Xeon® Scalable 5200 series, Intel® Xeon® Scalable 4200 series, Intel® Xeon® Scalable 3200 series
Maximum memory3.0 TB with 128 GB DDR4 DIMM
Memory slots24 DIMM slots
Memory protection featuresAdvanced ECC Memory Online Spare Mode Memory Lock Step Mode
Drive supported24 SFF SAS/SATA HDD/SSD, or 16 SFF SAS/SATA HDD/SSD and 8 SFF NVMe SSD. 12 LFF SAS/SATA HDD/SSD or 12 LFF NHP SATA HDD, depending on model. Upgrade option kits are available.
Processor core available28 or 26 or 24 or 22 or 20 or 18 or 16 or 14 or 12 or 10 or 6 or 8 or 4, depending on model
Processor cache38.50 MB L3 – 8.25 MB L3, depending on model
Processor number1 or 2
Processor speed3.9 GHz, maximum depending on processor
Memory typeHPE DDR4 SmartMemory
Memory, standard32 GB (1 x 32 GB) RDIMM or depending on model
Optical drive typeOptional DVD-ROM or DVD-RW. Optional via Slim-line ODD Bay Kit. Optional external support is available too. Optional Half-Height RDX or Tape, up to 2. Optional via Media Drive Support Kit. For detail reference QuickSpecs.
SecurityUEFI Secure Boot and Secure Start support Immutable Silicon Root of Trust FIPS 140-2 validation (iLO 5 certification in progress) Common Criteria certification (iLO 5 certification in progress) Configurable for PCI DSS compliance Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser Support for Commercial National Security Algorithms (CNSA) Tamper-free updates – components digitally signed and verified Secure Recovery – recover critical firmware to known good state on detection of compromised firmware Ability to rollback firmware Secure erase of NAND/User data TPM (Trusted Platform Module) 1.2 option TPM (Trusted Platform Module) 2.0 option Front bezel key-lock feature – standard, available in both Tower and Rack models Padlock slot, standard Kensington Lock slot, standard
Infrastructure managementHPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) (standard), HPE iLO Advanced, and OneView Advanced (optional)
Power supply typeHPE Flexible Slot Redundant Power Supply modules 500W / 800W / 1600W, depending on model SKU, or HPE Standard 500W Non-Hot-Plug/non-RPS Power Supply (ordering limited to non-EU/EMEA countries/regions)
Expansion Slots8-slots (x16, x8, x16, x8, x16, x8, x16, x8) as standard in 2P model. For detail reference QuickSpecs.
Network ControllerHPE Ethernet 1Gb 4-port 369i Adapter
Storage controller1 HPE Smart Array S100i and/or 1 HPE Smart Array P408i-a SR Gen10 and/or 1 HPE Smart Array E208i-a Gen10, depending on model. For detail reference QuickSpecs.
System fan featuresDepending on model SKU. Standard 2 fans, none-hot-plug. Optional 4 additional fans, hot-plug and N+1 redundancy Reference QuickSpecs for config. detail.
Form Factor4U tower with rack conversion capability
Warranty3/3/3 – Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: http://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, refer to the HPE website at http://www.hpe.com/support
Minimum dimensions ( H x W x D)18.2 x 25.51 x 6.85 in
Minimum dimensions ( H x W x D)46.25 x 64.8 x 17.4 cm
