Overview

Output
Max Configurable Power (Watts)
1.0kWatts / 1.44kVA
Output Voltage Distortion
Less than 5 %
Output Frequency (sync to mains)
50/60 Hz +/- 3 Hz Sync to mains
Other Output Voltages
110 V, 125 V
Topology
Line interactive
Waveform type
Sine wave
Transfer Time
6 ms typical : 10 ms maximum
Input
Input frequency
50/60 Hz +/- 3 Hz Auto-sensing
Input voltage range for main operations
75 – 154 Adjustable, 82 – 144V
Number of Power Cords
1
Other Input Voltages
110 V, 125 V
Batteries & Runtime
Battery type
Lead-acid battery
Typical recharge time
3hour(s)
Replacement Battery
Expected Battery Life (years)
3 – 5
RBC Quantity
1
Battery Charge Power (Watts)
136 Watts
Runtime
Efficiency
Communications & Management
Interface Port(s)
SmartSlot, USB
Control panel
Multifunction LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : configurable delays
Available SmartSlot™ Interface Quantity
1
Surge Protection and Filtering
Surge energy rating
680Joules
Filtering
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Physical
Maximum Height
8.62inches (219MM, 21.9CM)
Maximum Width
6.73inches (171MM, 17.1CM)
Maximum Depth
17.28inches (439MM, 43.9CM)
Net Weight
54.23lbs. (24.6KG)
Shipping weight
59.92lbs. (27.18KG)
Shipping Height
12.99inches (330MM, 33.0CM)
Shipping Width
12.99inches (330MM, 33.0CM)
Shipping Depth
23.23inches (590MM, 59.0CM)
Color
Black
Units per Pallet
12.0
Environmental
Operating Temperature
32 – 104 °F (0 – 40 °C)
Operating Relative Humidity
0 – 95 %
Operating Elevation
0 – 10000ft (0 – 3048meters)
Storage Temperature
-15 – 45 °C
Storage Relative Humidity
0 – 95 %
Storage Elevation
0 – 50000ft (0 – 15240meters)
Audible noise at 1 meter from surface of unit
45.0dBA
Online thermal dissipation
225.0BTU/hr
